Pioneer Hydraulic Rigid Mount Coupler for Kubota 3A111-82011
Product Fitment
| Make | Type | Model |
|---|---|---|
| Kubota | Industrial Tractor | L47 |
| Kubota | Tractor | L39, L45, M100X, M105S, M105X, M108S, M108X, M110, M110X, M120, M125X, M126X, M135X, M4700, M4900, M5040, M5640SU, M5700, M6040, M6800, M7040, M8200, M8540, M9000, M9540, M95S |
Product Features
Kubota Replacement Coupler
Rigid Mount Break-Away Coupler
State-of-the-Art Coupler Features Rigid Mounting and Connect/Disconnect Under Pressure
The Pioneer 0312-001 rigid mount coupler features a patented design that permits connection while both the coupler and male tip are under pressure.
These couplers can be mounted directly to a valve or rigid tubing, eliminating the need for hose assemblies and break-away clamps.
- Easy push/pull connection and disconnection under system pressure.
- Enclosed outer housing prevents dust and dirt build up.
- This coupler accepts all Pioneer 8010 Series or ISO 5675 male tips.
- Environmentally friendly Chromium 6 Free plating for excellent corrosion resistance
Product Specifications
| Coupler Body Size | 1/2 Inch |
|---|---|
| Thread Size | 7/8 - 14 ORB |
| Max PSI | 3000 PSI |
| Sleeve Operation | Push to Connect |
| Brand | Pioneer |
| Interchange Numbers | 0312-001, 3A111-82010, 3A111-82011, 3A111-82030 |
